BT40 FINE BORING HEAD SET EBOR60 RANGE 6-150 PULL STUD THREAD M16x2
THS014586
$ USD
240100
240100
| SKU | Boring range ØD | Suitable shank model | L1 | H |
| SKP003050 | 6-150 | BT40-ECK5-60 | 60 | 60 |
| SKP003051 | BT50-ECK5-75 | 75 | ||
| SKP003052 | SK40-ECK5-65 | 65 | ||
| SKP003053 | SK50-ECK5-75 | 75 | ||
| SKP003054 | DIN2080-40-ECK5-60 | 60 | ||
| SKP003055 | DIN2080-50-ECK5-75 | 75 | ||
| HSK-A63-EBOR60 | HSK-A63-ECK5-75 | 75 | ||
| HSK-A100-EBOR60 | HSK-A100-ECK5-75 | 75 |
| Boring shank spec. | Boring range | Depth M |
Insert | Insert Screw | Wrench | Cutting volume | Feed F |
| BR1606-20 | 6-9 | 20 | WBGT060102L | CSTB-2 | T6 | 0.05-0.2 | 0.05-0.1 |
| BR1608-28 | 8-11 | 28 | TBGT060102L | 0.05-0.2 | 0.05-0.1 | ||
| BR1610-36 | 10-13 | 36 | TBGT060104L | 0.1-0.25 | 0.07-0.15 | ||
| BR1612-42 | 12-15 | 42 | TPGT090202L | CSTB-2.5 | T8 | 0.05-0.2 | 0.05-0.1 |
| BR1614-50 | 14-17 | 50 | |||||
| BR1616-60 | 16-20 | 60 | |||||
| BR1620-63 | 20-24 | 63 | TPGT090204L | 0.1-0.25 | 0.07-0.15 | ||
| BR1624-64 | 24-28 | 64 | |||||
| BM5 | 60+SRTP2838/SRTP3652/SRTP4470 | M5x15CAP | 4 | 0.05-0.2 | 0.05-0.1 | ||
| SRTP2838 | 28-38 | +10 | TPGT090202L | CSTB-2.5 | T8 | ||
| SRTP3652 | 36-52 | +12 | |||||
| SRTP4470 | 44-70 | +12 | TPGT090204L | 0.07-0.15 | |||
| BM8 | M8x15CAP | 6 | |||||
| SRTP70110 | 70-110 | +20 | TPGT090202L | CSTB-2.5 | T8 | 0.05-0.1 | |
| SRTP110150 | 110-150 | +20 | TPGT090204L | 0.1-0.25 | 0.07-0.15 | ||
• The above is a complete tool package.
• The boring holder and shank can be ordered separately, please specify the details when ordering.
• The boring holder and shank can be ordered separately, please specify the details when ordering.
| DIRECTION | CAPACITY | PROJECTION | ROTATION | HAND | COOLANT | OFFSET |
| THS014586 BT40 FINE BORING HEAD SET EBOR60 RANGE 6-150 PULL STUD THREAD M16x2 | ||||||
|
|
||||||
| THS014589 BT50 FINE BORING HEAD SET EBOR60 RANGE 6-150 | ||||||
|
|
||||||
| THS014591 DIN2080-40 FINE BORING HEAD SET EBOR60 RANGE 6-150 | ||||||
|
|
||||||
| THS014595 DIN2080-50 FINE BORING HEAD SET EBOR60 RANGE 6-150 | ||||||
|
|
||||||
| THS014665 HSK100A BORING HEAD MICRO ADJUSTABLE SET RANGE 6-150 mm TYPE EBOR60 | ||||||
|
|
||||||
| THS014669 HSK63A BORING HEAD MICRO ADJUSTABLE SET RANGE 6-150 mm TYPE EBOR60 | ||||||
|
|
||||||
| THS014713 SK40 FINE BORING HEAD SET EBOR60 RANGE 6-150 | ||||||
|
|
||||||
| THS014717 SK50 FINE BORING HEAD SET EBOR60 RANGE 6-150 | ||||||
|
|
||||||
Updated 202505.11
Tool holder machine interface: CNC MILLING SPINDLE turret, BT-40, TAPER, ANY
